Genuine Mazda Timing Cover
Engine Timing Cover- Select Vehicle by Model
- Select Vehicle by VIN
Select Vehicle by Model
orMake
Model
Year
Select Vehicle by VIN
For the most accurate results, select vehicle by your VIN (Vehicle Identification Number).
69 Timing Covers found
Mazda Timing Cover Part Number: N3R1-10-500B
$822.37 MSRP: $1123.68You Save: $301.31 (27%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Front; Front Cover
Mazda Front Cover Part Number: YF09-10-500
$15.96 MSRP: $21.29You Save: $5.33 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Lower; Front Cover
- Position: Lower
Mazda Cover Part Number: PX9R-13-139A
$20.00 MSRP: $26.67You Save: $6.67 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Shield
- Replaces: PX9R-13-139
Mazda Timing Cover Part Number: B660-10-501E
$47.04 MSRP: $62.72You Save: $15.68 (25%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Lower; Front Cover, Outer Timing Cover
- Position: Left
Mazda Front Cover Part Number: YF09-10-510
$45.20 MSRP: $60.28You Save: $15.08 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Upper; Front Cover
- Position: Upper
Mazda Timing Cover Part Number: B660-10-521B
$48.59 MSRP: $64.80You Save: $16.21 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing; Front Cover, Outer Timing Cover
- Position: Right
- Replaces: B660-10-521A, B660-10-520B
Mazda Outer Timing Cover Part Number: BP6D-10-511
$57.20 MSRP: $76.28You Save: $19.08 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover(Upper), Timing Chain
- Position: Outer
Mazda Timing Cover Part Number: B6BF-10-511A
$59.03 MSRP: $78.72You Save: $19.69 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover(Upper), Timing Chain; Front Cover
Mazda Front Cover Part Number: FP01-10-520C
$67.75 MSRP: $90.35You Save: $22.60 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Upper; Front Cover
- Position: Upper
Mazda Timing Cover Part Number: FS01-10-520C
$75.19 MSRP: $100.26You Save: $25.07 (25%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt Upper; Front Cover
Mazda Front Cover Part Number: FP33-10-500
$71.49 MSRP: $95.33You Save: $23.84 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Lower; Front Cover
- Position: Lower
Mazda Front Cover Part Number: B61P-10-510
$92.96 MSRP: $123.98You Save: $31.02 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover Upper, Timing Chain; Outer Timing Cover
- Position: Front
Mazda Timing Cover Part Number: FS01-10-500D
$96.48 MSRP: $128.66You Save: $32.18 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt Lower; Front Cover
- Replaces: FS01-10-500C
Mazda Timing Cover Part Number: KJ01-10-510B
$111.25 MSRP: $148.37You Save: $37.12 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Belt-Upper; Timing Cover
- Position: Front
- Replaces: KJ01-10-510
Mazda Timing Cover Part Number: CY01-10-500D
$124.95 MSRP: $166.63You Save: $41.68 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Chain; Front Cover
- Replaces: CY01-10-500B, CY01-10-500, CY01-10-500C, CY01-10-500A, ZZJ1-10-500, ZZJ1-10-500A
Mazda Timing Cover Part Number: KL01-10-500E
$128.55 MSRP: $171.44You Save: $42.89 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover(Right), Timing Belt; Timing Cover, Upper Timing Cover
- Position: Right
- Replaces: KL01-10-500C, KL01-10-500D
Mazda Timing Cover Part Number: KL01-10-510C
$128.66 MSRP: $171.58You Save: $42.92 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover(Left), Timing Belt; Timing Cover, Upper Timing Cover
- Position: Left
Mazda Timing Cover Part Number: AJ03-10-500D
$127.60 MSRP: $170.17You Save: $42.57 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover, Timing Chain; Front Cover
Mazda Timing Cover Part Number: KJ01-10-500A
$159.50 MSRP: $212.71You Save: $53.21 (26%)Ships in 1-2 Business DaysProduct Specifications- Other Name: Cover(Right), Timing Belt; Timing Cover
- Position: Right
Mazda Timing Cover Part Number: L3G2-10-500E
Product Specifications- Other Name: Cover, Timing Chain; Front Cover
- Replaces: L3G2-10-500C, L3G2-10-500A, L3G2-10-500D, L3G2-10-500, L3G2-10-500B
| Page 1 of 4 |Next >
1-20 of 69 Results
Mazda Timing Cover
The Mazda timing cover is designed to protect the car's timing belt, camshaft belt, or time chain from dirt, debris, and stones. The timing belt may jump off its gear or even break if it does not have this protection while under operation. Most commonly, timing covers are made up of plastic, metal, or a combination of both materials. However, no matter how tough the material is, there is one day for your Mazda timing cover to fail. Given below are some examples of signs that may indicate that your timing cover could be bad: engine oil leakage or engine coolant leakage in the vehicle; noises such as rattling or grinding coming from the front end of the engine; missed timing marks, which indicate misalignments. Regularly examine your timing cover, including the gasket, to ensure it functions properly.
Whenever you need replacements, opt for genuine Mazda Timing Covers. Because they meet the manufacturer's criteria, it guarantees that replacements fit perfectly. Thus, these make better choices for people who care about driving. Why should you shop at MazdaPartsNow.com? We sell genuine Mazda Timing Covers. In our online catalog, there is a wide range of different parts. These are delivered directly from authorized Mazda dealers only so that customers can be sure of their security throughout any transaction while using our website. Furthermore, you can also quickly search for OEM parts you want because of our user-friendly site navigation. Choose us for a genuine Mazda Timing Cover that keeps your car running like new.
Mazda Timing Cover Parts and Q&A
- Q: How to remove the Timing Chain, Timing Chain Tensioner and Timing Cover on Mazda 3?A:The timing chain cover can be removed by firstly disconnecting the negative battery terminal by first removing the battery cover. Unscrew the water pump pulleys bolts and take out the drive belt, drive belt idler pulley and the water pump pulley. The second step is to take the crankshaft pulley off making sure that the engine does not leave TDC. Removal of the upper engine cover: Lift off the engine cover uppermost on the mounting posts and disconnect the electrical connector of Crankshaft Position (CKP) sensor, and remove the sensor, remember that sensor needs to be replaced every time. Access the engine by lifting it at the top and lift it so that one can take off the engine mount to the right and should one be required, loosen the mounting bracket and lay aside the power steering hoses. Take off the timing chain cover by removing the crankshaft front oil seal then the bolts. Installation requires reversal of the removal instructions with the note to clean all surfaces of the parts of the sealant mating, installing the engine cover within the four minutes following the application of RTV sealant, tightening the bolts in sequence to the recommended torque, and fitting a new CKP sensor with the alignment tool without tightening the mounting bolts of the sensor. In order to strip the timing chain and tensioner, you have to remove the timing chain cover, then pull the ratchet arm of the tensioner couple of inches away by the ratchet stem and press the tensioner piston by pushing on it using a pin. In the event that the ratchet requires resetting, put the tensioner in the vise, release the tension and put the ratchet back in place. Disassemble the tensioner mounting bolts and tensioner, the loose timing chain guide and timing chain. The camshaft sprockets and guide to the left chain may be removed in case of necessity. To install, first remove the camshaft alignment tool (unless it was already installed), loosen the camshaft sprocket bolts but do not remove them and then install the left chain guide (unless removed). Next, place the timing chain and the right chain guide, the timing chain tensioner, screw the fastensers and then eliminate the pin to connect the chain guide. Tighten the bolts of the camshaft sprocket and install the camshaft alignment tool again, when doing so, do not depend on the alignment tool. Lastly, the timing chain cover could be fitted.
- Q: How to remove and install Timing Cover for Timing Chain on Mazda B2200?A:To install/remove parts of 2.6L engine of 1987-88, start with disconnection of the negative battery cable and air cleaner assembly, power steering drive belts, alternator, power steering pump, and air conditioning compressor. Place the vehicle on jackstands, empty the engine oil and remove the crankshaft pulley. Reduce the vehicle and put a jack below the engine and release pressure to take off the right engine mount center bolt. Proceed to take off the engine oil dipstick, valve cover, and certain bolts of the cylinder head and oil pan followed by the timing chain case cover and check it against damage. Installation involves placing a new timing chain case cover gasket, sealant and tightening the mounting bolts. Install the oil pan, engine mounting plate, crankshaft pulley, right engine mount, valve cover, dipstick, air conditioning compressor, power steering pump, alternator, accessory drive belts, pour the crankcase with oil and re-connect the negative battery cable. In the 1989-93 model, disconnection of battery ground, drainage of cooling system, accessory drive belts, tan and shroud, water pump pulley, water pump, crankshaft pulley and oil pan are also to be disconnected. Unscrew and take off the timing chain cover, fit a new wafer inlet pipe gasket and oil pick-up tube using new gaskets and screw the bolts. Install the oil pan, crankshaft pulley, water pump, water pump pulley, fan, shroud, accessory drive belts, fill the cooling system and connect the battery ground. In the case of the 4.QL engine, unscrew the negative battery cable, empty the cooling system, and take out the radiator as well as the oil pan. Removal - remove the air conditioning compressor, power steering pump, without disconnecting the hoses, the alternator, fan, water pump, drive pulley/damper, and crankshaft timing sensor. Install the front cover and radiator, crankshaft position sensor, drive pulley/damper, water pump, fan, and alternator, remove the front cover that has bolts, fill the radiator, replace the oil pan, fill the crankcase with engine oil, reconnect the negative battery cable, start the engine, check leaks and road test the car.
